Wago 770-609 Distributor 3 way 5 pole black 400V 25A

(Item no.: 200499)
Wago 770-609 Distributor 3 way 5 pole black 400V 25A Wago 770-609 Distributor 3 way 5 pole black 400V 25A
Wago 770-609 Distributor 3 way 5 pole black 400V 25A Wago 770-609 Distributor 3 way 5 pole black 400V 25A
Wago 770-609 Distributor 3 way 5 pole black 400V 25A

Halogen free: Yes
Pollution degree: 3
Assigned impulse voltage: 6 kV
Max. continuous temperature resistance contact part: 85 ° C
Number of poles: 5
Mechanical coding: Yes
Lockable: Yes
Resistant to a continuous temperature up to: 85 ° C
Max. continuous temperature resistance strain relief: 105 ° C
Confirmation option: Yes
Locking type: Integrated in plug-in connector
Nom. (measuring) voltage: 400 V.
Nom. (measuring) current: 25 A.
Housing material: Polyamide (PA)
Passage resistance: 0.5 mOhm
Nom. (measuring) current to luminaire: 25 A.
Number of inputs: 5
Confirmation option: No.
Number of outputs: 15

Condition: New

Product number

200499

Default delivery time

Products in stock are shipped the same day

EAN

4045454251383

Stock

71

€ 6,37
excl. VAT
€ 7,71
incl. VAT
Price per piece
Quantity:
Order

Do you have a question about this product?

Ask us your question

+31 6 10588401 Whatsapp

Information:

General specifications

Brand
Wago
Series
WINSTA® MIDI
Article number
770-609
Dimensions
46 x 50 x 36,7 mm
IP protection rating
IP20
Product condition
New
Origin
Bankruptcy

Technical specifications

Number of poles
5
Current Rating
25 A
